Product usage :
It is suitable for working environment and air ventilation equipment with strict fire protection requirements, and is widely used in the filtration of ventilation and air conditioning systems of subways, high-speed trains, high-speed railways, etc.;
Features:
· with high dust capacity and low resistance; · silicone-free and resistant to chemicals such as chemical solvents and acid smog; · long service life, multiple-use after vacuuming or cleaning, economical and practical; · PET organic synthetic fiber with high performance, high strength, and fracture resistance is adopted to make it by step encryption and incremental structure, combing and laying the hot air; · paper frame and metal frame are mostly used to make plank filter and pleat filter and can be used as pocket filter.
Specifications:
Model | Configuration Size | Initial resistance(Pa) | Rated air velocity(m/s) | Rated Air Flow (m³/h) |
C100 | 20m*1/2m*5mm | ≤30 | 1.5 | 5400 |
C200 | 20m*1/2m*10mm | ≤30 | 1.5 | 5400 |
C250 | 20m*1/2m*(15-20)mm | ≤30 | 1.5 | 5400 |
C300 | 20m*1/2m*20mm | ≤30 | 1.5 | 5400 |
Note: other specifications can be customized according to requirements.
Technical datasheet:
Filtration class | G4(EN779)、G4(EUROVENT) |
Moisture resistance (relative humidity) | ≤99%RH |
Final resistance | 250Pa(suggestion) |
Average weighing efficiency | 95%(ASHRAE52.1-1992) |
Flame-retardant grade | F1(DIN 53438)、B1(GB/T 17591-2006) |
Temperature-instant | 120℃ |
Filter object | Coarse dust and foreign matter ≥5μm |
Temperature-resistant | ≤100℃ |
Dust holding capacity | 500g/m² 、600g/m² |
